Chapter 8 The 9130 VSWR/DTF Reflection Measurement Option
Measurement modes
9102 Handheld Spectrum Analyzer Software version 5.31
139
Measurement modes
The 9130 VSWR/DTF Reflection Measurement Option offers three
additional measurement modes: reflection, distance to fault and cable
loss. If the 9130 VSWR/DTF Reflection Measurement Option is installed
and activated on your 9102, three additional submenus besides signal
generator and transmission are available in the VSWR/Tracking...
submenu:
– Reflection
This mode enables you to test performance and match of antenna
systems over the desired frequency range in one view.
For a description of measurements using the reflection mode refer
to “Reflection Operation” on page 143.
– Distance to Fault
This mode puts the attention on the cable and offers a detailed
analysis of feeder cables. Cable-related problems can be easily
detected and located.
For a description of measurements using the distance to fault
mode refer to “Distance to Fault Operation” on page 163.
– Cable Loss
The cable loss mode allows you to determine the average cable
loss.
For a description of measurements using the distance to fault
mode refer to “Cable Loss Operation” on page 173.
For details on selecting a measurement mode refer to “Selecting the
measurement mode” on page 29.
Figure 41 VSWR/Tracking menu
