Chapter 16 SCPI Command Reference
System commands
9102 Handheld Spectrum Analyzer Software version 5.31
265
:SYSTem:COMMunicate:LOCal
:SYSTem:COMMunicate:ECHO
:SYSTem:COMMunicate:ETHernet?
Syntax
:SYSTem:COMMunicate:LOCal
Parameters
There are no parameters.
Command
Sets up the 9102 to allow manual operation on the front panel during SCPI
operation.
Notes:
– This command may be used e.g. to allow interactive alignment procedures in a
production flow.
– The instrument can also be set to local mode by pressing the Escape function key
on the front panel.
Query
There is no query form of this command available.
Example
:SYSTem:COMM:LOC
Syntax
:SYSTem:COMMunicate:ECHo <PredefExpr>
Parameters
PredefExpr is one of the following predefined expressions: ON|OFF.
Default is ON.
Command
This command determines how the Aeroflex 9102 acts after executing a
SCPI command.
If echo is set to ON, there will be a response. Either "ok", if the execution
was successful or "ERR" if an error occured. The echo-on mode is pre-
ferred for entering interactive commands.
If echo is set to OFF, there will be no response to a SCPI command. In this
case it is possible to check with the *OPC? query, when the SCPI command
is finished and the Aeroflex 9102 is ready to receive the next command.
Query
Reads and returns the current echo setting.
Example
:SYST:COMM:ECH ON
Returns the following string: "ok"
All subsequent commands returns "ok" or "ERR".
:SYST:COMM:ECH?
Returns the following string: "ON"
:SYST:COMM:ECH OFF
Returns nothing, all subsequent commands return nothing.
Syntax
:SYSTem:COMMunicate:ETHernet?
Parameters
There are no parameters.
Command
There is solely a query form of this command available.
Query
Returns ON,
if the Aeroflex 9102 is connected to a local area network (LAN)
via TCP/IP connector, otherwise returns OFF
.
Example
:SYSTem:COMM:ETH?
String returned in this example: "OFF"
