Chapter 14 Updating the Instrument Software
Performing a LAN update
9102 Handheld Spectrum Analyzer Software version 5.31
221
Performing a LAN update
The software update requires a 9100 software update file, which is an
executable file running on a Windows PC that also includes the soft-
ware update for your 9102 Handheld Spectrum Analyzer. Such a file
can be downloaded from Aeroflex’s website, e.g. the file
9100Setup_4_50.exe.
Take the following steps to perform a LAN update of the instrument’s
software via the Setup Application Software menu:
1 Connect the 9102 to an external power supply.
2 Connect the 9102 to the PC. See section “Connecting the 9102
Handheld Spectrum Analyzer” on page 14 for further details.
3 Switch on the 9102. In order to enter the Setup Application Soft-
ware menu press the numeric key 0 when the input request
message is displayed on the boot-up screen. Now the Setup Appli-
cation Software menu is displayed.
4 Press the numeric key 2 to open the LAN Update menu.
5 Here the IP adresses of the instrument (Target IP) and the PC (Host
IP) are displayed. Press the numeric key 1 to change or enter the
Host IP and 2 to change the Target IP. See section “Determining the
Host IP address” on page 222 for information on determining the
Host PC’s IP address.
6 In order to upload the application files from the PC to the instru-
ment start the installation program on your PC. This will open the
Update window (see “Performing a serial update” on page 219).
7 In the Connection section, select
LAN.
8 In order to start the update press the numeric key 6 on the instru-
ment.
A message prompts you to press any key to start the update or to
hit the ESC key to abort the update.
9 Press the E
NTER key to start the update.
Both the instrument and the installation program on the PC display
the progress of the software update.
NOTE
You do not have to click on
Start in the Update window on your PC.
The update process will be started without any further input on the
PC.
NOTE
You do not have to click on
Start in the Update window on your PC.
The update process will be started without any further input on the
PC.
