Chapter 1 Overview
Physical description
10 9102 Handheld Spectrum Analyzer Software version 5.31
Physical description
The 9102 Handheld Spectrum Analyzer is delivered with the 9100 Data
Exchange Software which can also be ordered separately.
The user-accessible parts of the 9102 can be broken down into several
sections:
– Front panel with large screen, softkeys, numeric, cursor and func-
tion keys.
– Connectors accessible from the top and the left-hand side of the
9102.
– On/off switch, power supply connector and battery shelf.
– Handle which can be turned in steps to serve as a stand, allowing
the 9102 to be operated at an angle.
Maintaining your unit
The 9102 Handheld Spectrum Analyzer is a measurement device. As
with all such instruments, the 9102 should be calibrated on a regular
basis to ensure accuracy. Aeroflex recommends calibration of the
9102 at yearly intervals.
Please take also advantage of our Frequently Asked Questions and our
electronic newsletter, both available on the Internet.
Attenuator 18 GHz, 6 dB
Calibration Set Open/Short/
Load, type DIN 7/16 inch
male
Calibration Set Open/Short/
Load,
type N male
To Next Page
