Chapter 1 Overview
Features and capabilities
9102 Handheld Spectrum Analyzer Software version 5.31
5
– Improved Color Scheme menu: eight input fields available for all
screen components
Version 3.01 New feature:
New function in the Trace Function menu: Add A + B
A. For a
description of these functions refer to the “Setting up the trace”
sections of in Chapter 3 “Spectrum Analysis Operation” and
Chapter 4 “Channel Power Operation”.
Improvement:
Measure menu improved. Access to Measure menu from Spectrum
Analysis main menu.
Features and capabilities
– VSWR and DTF measurements supporting antenna installation and
verification (option)
– Tracking generator option enables cable measurements in the field
– Radiation measurements of base stations and broadcast stations
(EMF option)
– Scalar network analysis (amplifier gain over frequency or filter char-
acteristics) and antenna measurements
– Prequalification for EMC (electromagnetic compatibility) tests
– Displayed average noise level at –117 dBm
– Dynamic range of 70 dB
Options and accessories
The following options and acessories are available:
Table 4 Options for the 9102 Handheld Spectrum Analyzer
Order
number
Description
AG 897 261 9130 VSWR/DTF Reflection Measurement Option
AG 897 274 9131 EMF Measurement Option
AG 897 275 9132 RMS Detector Option
AG 248 966 9160 VSWR/DTF Bridge
AG 248 804 Tracking Generator Upgrade
AG 248 811 9168 GPS Receiver Option
AG 248 968 9162 Insertion Power Sensor
