Chapter 16 SCPI Command Reference
Sense commands
288 9102 Handheld Spectrum Analyzer Software version 5.31
:SENSe:TRANsmission:REFerence
:SENSe:TRANsmission:REFerence:UNIT
:SENSe:EMF:REFerence
Example
:SENSe:DTF:CALibration:ENABled OFF
:SENSe:DTF:CALibration:ENABled?
Returns the following string: "OFF"
Syntax
:SENSe:TRANsmission:REFerence <real1>
Parameters
real1
is a floating point real number.
The minimum value for real1 is -60.0 dB
. The maximum value for
real1 is 60.0 dB. The default value for real1 is 0.0 dB.
Command
This command sets the reference of the
9102 (0 dB line), in Transmission
mode. The reference refers to the current set output power level of the
tracking generator.
Query
Reads and returns the current setting.
Example
:SENSe:TRANsmission:REFerence -10
:SENSe:TRANsmission:REFerence?
The value returned in this example is: "-10"
.
Syntax
:SENSe:TRANsmission:REFerence:UNIT <PredefExpr>
Parameters
PredefExpr is one of the following predefined expressions:
DB|DBM|.
Default is DB.
Command
Switches the display absolute or relative to the tracking generator output
power. This command is linked to INSTrument:GENerator:DISPlay
.
Query
Reads and returns the current setting.
Example
:SENSe:TRANsmission:REFerence:UNIT DBM
:SENSe:TRANsmission:REFerence:UNIT?
Returns the following string: "DBM"
Syntax
:SENSe:EMF:REFerence <real1>
Parameters
real1 is a floating point real number.
The minimum- and maximum value for real1 depend on the unit set by
SENS:EMF:REFerence:UNIT. When the unit is set to dBm/m^2, the mini-
mum value is -100, the maximum value is 30. When the unit is set to
dBuV/m, the minimum value is 7, the maximum value is 137. When the unit
is set to dBmV/m, the minimum value is -53, the maximum value is 77.
When the unit is set to dBV/m, the minimum value is -113, the maximum
value is 17. When the unit is set to V/m, the minimum value is
0.000002236, the maximum value is 7.0710678. When the unit is set to
mW/m^2, the minimum value is 0.0001, the maximum value is 1000.0. The
default value for real1 is 107.0 dBµV/m.
Command
This command sets the EMF reference level of the 9102, in the unit
selected with the :SENS:EMF:REFerence:UNIT command.
Query
Reads and returns the current setting.
