Chapter 15 9100 Data Exchange Software
Saving, loading and printing results on the PC
9102 Handheld Spectrum Analyzer Software version 5.31
231
Saving, loading and printing results on the PC
Once a measurement trace has been transferred to the PC, it can be
stored on the hard disk, printed or exported to a graphics or text file.
Storing results on the PC The trace, along with the 9102 settings and markers, can be saved in a
file and loaded again in a trace file. This way, information about settings
and individual result values will not be lost.
1 Select
File > Save or File > Save As ....
A window with a file selection box appears.
2 Select a directory and a file name to save the trace data, and
confirm by pressing E
NTER.
The trace data are saved in a file.
Loading a trace file on
the PC
Results previously stored on the PC can be retrieved and displayed in
the 9100 Data Exchange Software.
1 Select
File > Open.
A window with a file selection box appears.
2 Select the directory and the file name containing the trace data,
and confirm by pressing E
NTER.
The trace data are loaded to the 9100 Data Exchange Software.
Printing measurement
results
Affecting the layout The following steps help you to choose the best format for your print-
out:
1 Select
File > Print Setup... and set up the correct printer, the paper
orientation and printer-dependent settings. Confirm the changes
made by pressing E
NTER.
2 Select
Edit > Additional Information... to enter text for two columns
of header information that is to be printed with the trace. The trace
is printed with the filename; use the check box “Show File Path” to
include complete information about the folder where the trace file
is located.
NOTE
*9tr trace files can also be transferred in both directions using the
Traces tab in the
Instrument > Data Transfer... menu.
