Chapter 2 General Operation
Printing
38 9102 Handheld Spectrum Analyzer Software version 5.31
3 Push the HOLD/RUN softkey to start the measurement.
Both the measurement counter and the failure counter start from 0.
When the selected number of traces has been reached, the
measurements are stopped and you can read the failure count.
Resetting the counter The failure counter for the limits check can be reset by turning it off and
then on again (in the
Level > Limits Evaluation menu).
Enabling a beep upon
failures
1 From the main menu, select Level > Limits Evaluation.
The Limits Evaluation menu appears.
2 Push the
Fail Beep softkey to activate or deactivate the beep
counter:
If activated, a beep sounds each time the measured signal exceeds
the limits.
Viewing a failed
measurement
This feature can be useful if you want to stop the measurement and
view the measured signal when it fails the limits. Note that the 9102
should be set to continuous measurements.
1 From the main menu, select
Level > Limits Evaluation.
2 Push the
Fail Hold softkey once or twice to enable or disable the
hold-on-fail function.
The measurements are halted when a failure occurs. The trace of
the failed signal remains on screen.
Measurements can also be stored and recalled in the 9102 for later
analysis or comparison. This is shown in “Storing and loading traces”
on page 73.
With the 9100 Data Exchange Software, traces can also be transferred
to and viewed and stored on a PC. For more details, please refer to
chapter “9100 Data Exchange Software” on page 223.
Printing
The 9102 offers the possibility of printing measurement results, for
example traces, directly from the instrument. In order to print results
screens on a connected printer simply press the ± key on the numeric
keypad of the 9102’s front panel.
NOTE
If an input field is active while you press the ± key, it has the ± func-
tionality assigned to it. In this case printing is not possible. In order to
be able to print deactivate the input field first by deselecting the
respective softkey.
