Predefined cable types
9102 Handheld Spectrum Analyzer Software version 5.31
363
Predefined cable types
For DTF measurements in the distance to fault measurement mode
Aeroflex provides predefined cable types for most known coaxial
cables. These cable types are available in the 9100 Data Exchange
Software. You can upload the cable types you use frequently to the
9102. For further details on the usage of cable types in distance to fault
measurements refer to “Specifying cable settings” on page 166. For
information on managing cable types within the 9100 Data Exchange
Software refer to “Managing cable types for distance-to-fault measure-
ments” on page 246.
The following table provides an overview on all predefined cable types
implemented in the 9100 Data Exchange Software.
Table 4 9100 Data Exchange Software cable types
Cable type Description
Velocity
(Vf %)
Attn.
(dB/
100m)
Dielec.
ANAVA5-50 AVA5-50 7/8" 91.00 5.530 1.21
ANAVA7-50 AVA7-50 1 5/
8"
92.00 3.360 1.18
ANEFX2-50 EFX2-50 85.00 17.800 1.38
ANFSJ1-
50A
FSJ1-50A 84.00 28.500 1.42
ANFSJ2-50 FSJ2-50 83.00 19.600 1.45
ANFSJ4-
50B
FSJ4-50B 81.00 17. 60 0 1.52
ANHJ12-50 HJ12-50 93.10 2.890 1.15
ANHJ45-50 HJ4.5-50 92.00 7. 86 0 1.18
ANHJ4-50 HJ4-50 91.40 13.700 1.20
ANHJ5-50 HJ5-50 91.60 6.260 1.19
ANHJ7-50A HJ7-50A 92.10 3.420 1.18
ANHL4RP-
50
HL4RP-50 88.00 12.200 1.29
ANLDF12-
50
LDF12-50 88.00 3.260 1.29
ANLDF1-50 LDF1-50 86.00 20.000 1.35
ANLDF2-50 LDF2-50 88.00 17.000 1.29
ANLDF45-
50A
LDF4.5-50A 89.00 8.020 1.26
ANLDF4-
50A
LDF4-50A 88.00 10.700 1.29
