Chapter 16 SCPI Command Reference
MMemory commands
300 9102 Handheld Spectrum Analyzer Software version 5.31
:MMEMory:STORe:TRACe
:MMEMory:STORe:LIMit
Command
Stores the actual parameter settings of the 9102 in the SETTINGS directory
on the flash disk in a file named <string1>.
Query
Reads and returns the file name last stored with this command.
Example
:MMEMory:STORe:STATe "sett3"
Syntax
:MMEMory:STORe:TRACe <string1>[,<PredefExp>]
Parameters
string1 is a string (text) parameter. The maximum length of string1 is
11 characters.
PredefExpr is an optional parameter and one of the following predefined
expressions: A|B. Default is A.
Command
Stores the current trace A or B and the parameter settings on the flash disk
in the TRACE directory in a file named <string1>.
Query
Reads and returns the file name last stored with this command.
Example
:MMEMory:STORe:TRACe "GSM900",A
Syntax
:MMEMory:STORe:LIMit
<string1>{,<PredefExpr>,<x1>,<y1>,<x2>,<y2>...}
:MMEMory:STORe:LIMit? <string1>
Parameters
string1 is a string (text) parameter. The maximum length of string1 is
11 characters.
PredefExpr
is one of the following predefined expressions:
MINimium|MAXimum
.
x1 y1 x2 y2 are floating point real numbers.
The minimum value for all these reals is 0, the maximum value for the x val-
ues is 10, the maximum value for the y values is 8, the resolution for all real
values is 0.1 and the default is 0.
Command
Stores the limits defined as lines in the LIMIT directory on the flash disk in a
file named <string1>. A line is defined by a parameter set
PredefExpr,x1,y1,x2,y2. Up to 30 parameter sets can follow the
string parameter.
Query
Reads and returns the parameter sets of the limit file which is given as
parameter.
Example
:MMEMory:STORe:LIMit
"lim2",UPP,2.3,4.5,6.9,7,2,LOW,2.3,1.5,6.9,3,2
:MMEMory:STORe:LIMit? "lim2"
String returned: UPP,2.3,4.5,6.9,7,2,LOW,2.3,1.5,6.9,3,2
