10 InfiniiVision 7000B Series Oscilloscopes User’s Guide
Contents
Using Labels 89
To turn the label display on or off 89
To assign a predefined label to a channel 90
To define a new label 91
To load a list of labels from a text file you create 92
To reset the label library to the factory default 93
4Triggering95
Triggering - General Information 97
Trigger Mode and Coupling Menu 98
Auto and Normal Trigger modes 99
Choosing Auto Trigger Mode or Normal Trigger Mode 99
Auto Mode 100
Normal Mode 100
Trigger Level Adjustment 102
Trigger Coupling 103
Trigger Noise Rejection 104
HF Reject 105
LF Reject 105
Noise Rejection 106
Trigger Holdoff 107
Trigger Holdoff Operating Hints 107
To set holdoff 107
External Trigger Input 109
2-Channel Oscilloscope External Trigger Input 109
Maximum voltage at 2-channel oscilloscope external trigger input 110
4-Channel Oscilloscope External Trigger Input 111
Maximum voltage at 4-channel oscilloscope external trigger input 111
