UART/RS232 Triggering and Serial Decode 15
InfiniiVision 7000B Series Oscilloscopes User’s Guide 337
7 If Burst is selected, an idle time (1 s to 10 s) can be specified so that
the oscilloscope will look for a trigger condition only after the idle time
has past. Press the Idle softkey and rotate the Entry knob to set an idle
time.
8 Remember to set the trigger mode to Normal (press [Mode/Coupling] >
Mode > Normal) to prevent Auto Triggering.
To display UART/RS232 serial decode, see “UART/RS232 Serial Decode” on page 338.
