User's Manual 330 Document #: LTRT-10632
Mediant 800B Gateway & E-SBC
thresholds, and then click the Quality of Experience Color Rules link located below the
table; the Quality of Experience Color Rules table appears.
6. Click New; the following dialog box appears:
Figure 16-4: Quality of Experience Color Rules Table - Dialog Box
7. Configure a rule according to the parameters described in the table below.
8. Click New, and then save your settings to flash memory.
Table 16-3: Quality of Experience Color Rules Table Parameter Descriptions
Parameter Description
General
Index
index
[QOEColorRules_ColorRuleIndex]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
Monitored Parameter
monitored-parameter
[QOEColorRules_monitoredParam]
Defines the parameter to monitor and report.
 [0] MOS (default)
 [1] Delay
 [2] Packet Loss
 [3] Jitter

[4]
RERL [Echo]
Direction
direction
[QOEColorRules_direction]
Defines the monitoring direction.
 [0] Device Side (default)
 [1] Remote Side
Sensitivity Level
sensitivity-level
[QOEColorRules_profile]
Defines the sensitivity level of the thresholds.
 [0] User Defined = Need to define the thresholds in the
parameters described below.
 [1] Low = Pre-configured low sensitivity threshold values. Thus,
reporting is done only if changes in parameters' values are
significant.
 [2] Medium = (Default) Pre-configured medium sensitivity
threshold values.
 [3] High = Pre-configured high sensitivity threshold values. Thus,
reporting is done for small fluctuations in parameter values.
Thresholds
