User's Manual 564 Document #: LTRT-10632
Mediant 800B Gateway & E-SBC
2. Click New; the following dialog box appears:
Figure 25-3: Calling Name Manipulation for IP-to-Tel Calls Table (Example) - Add Dialog Box
3. Configure a manipulation rule according to the parameters described in the table
below.
4. Click Apply.
Table 25-4: Calling Name Manipulation Tables Parameter Descriptions
Parameter Description
General
Index
[_Index]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
Name
manipulation-name
[_ManipulationName]
Defines a descriptive name, which is used when associating the row in
other tables.
The valid value is a string of up to 40 characters.
Note: Each row must be configured with a unique name.
Match
Destination Prefix
dst-prefix
[_DestinationPrefix]
Defines the destination (called) telephone number prefix and/or suffix.
You can use special notations for denoting the prefix. For example,
[100-199](100,101,105) denotes a number that starts with 100 to 199
and ends with 100, 101 or 105. You can also use the $ sign to denote
calls without a called number. For a description of available notations,
see 'Dialing Plan Notation for Routing and Manipulation Tables' on
page 1051.
The default value is the asterisk (*) symbol (i.e., any destination prefix).
Source Prefix
src-prefix
[_SourcePrefix]
Defines the source (calling) telephone number prefix and/or suffix.
You can use special notations for denoting the prefix. For example,
[100-199](100,101,105) denotes a number that starts with 100 to 199
and ends with 100, 101 or 105. You can also use the $ sign to denote
calls without a calling number. For a description of available notations,
see 'Dialing Plan Notation for Routing and Manipulation Tables' on
page 1051.
