Version 7.2 565 Mediant 800B Gateway & E-SBC
User's Manual 25. Manipulation
Parameter Description
The default value is the asterisk (*) symbol (i.e., any source prefix).
Calling Name Prefix
calling-name-prefix
[_CallingNamePrefix]
Defines the caller name (i.e., caller ID) prefix.
You can use special notations for denoting the prefix. For example, to
denote calls without a calling name, use the $ sign. For a description of
available notations, see 'Dialing Plan Notation for Routing and
Manipulation Tables' on page 1051.
The default value is the asterisk (*) symbol (i.e., any calling name
prefix).
Source Trunk Group ID
src-trunk-group-id
[_SrcTrunkGroupID]
Defines the source Trunk Group ID from where the Tel-to-IP call was
received.
The default value is -1, which denotes any Trunk Group.
Note: The parameter is applicable only to the Calling Name
Manipulation for Tel-to-IP Calls table.
Source IP Address
src-ip-address
[_SourceAddress]
Defines the source IP address of the caller for IP-to-Tel calls. The
source IP address appears in the SIP Contact header in the INVITE
message.
The default value is the asterisk (*) symbol (i.e., any IP address). The
source IP address can include the following wildcards:
ï‚§ "x" wildcard: represents single digits. For example, 10.8.8.xx
represents all IP addresses between 10.8.8.10 to 10.8.8.99.
ï‚§ "*" (asterisk) wildcard: represents any number between 0 and 255.
For example, 10.8.8.* represents all IP addresses between 10.8.8.0
and 10.8.8.255.
Note: The parameter is applicable only to the Calling Name
Manipulation for IP-to-Tel Calls table.
Source Host Prefix
src-host-prefix
[_SrcHost]
Defines the URI host name prefix of the incoming SIP INVITE message
in the From header.
The default value is the asterisk (*) symbol (i.e., any source host prefix).
Note:
ï‚§ The parameter is applicable only to the Calling Name Manipulation
for IP-to-Tel Calls table.
ï‚§ If the P-Asserted-Identity header is present in the incoming INVITE
message, the value of the parameter is compared to the P-Asserted-
Identity URI host name (instead of the From header).
Destination Host Prefix
dst-host-prefix
[_DestHost]
Defines the Request-URI host name prefix of the incoming SIP INVITE
message.
The default value is the asterisk (*) symbol (i.e., any destination host
prefix).
Note: The parameter is applicable only to the Calling Name
Manipulation for IP-to-Tel Calls table.
Action
Stripped Characters From
Left
remove-from-left
[_RemoveFromLeft]
Defines the number of characters to remove from the left of the calling
name.
For example, if you enter 3 and the calling name is "company:john", the
new calling name is "pany:john".
Stripped Characters From
Defines the number of characters to remove from the right of the calling
