User's Manual 620 Document #: LTRT-10632
Mediant 800B Gateway & E-SBC
2. Click New; the following dialog box appears:
Figure 27-14: Supplementary Services Table - Add Dialog Box
3. Configure a supplementary service according to the parameters described in the table
below.
4. Click Apply.
You can also register and un-register an endpoint configured in the table:
To register or un-register an endpoint:
1. In the Trunk Group Settings table (see 'Configuring Trunk Group Settings' on page
519), configure the registration method using the 'Registration Mode' parameter.
2. In the Supplementary Services table, select the required endpoint.
3. From the 'Action' drop-down list, select Register. To unregister the endpoint, select
Un-Register.
Table 27-6: Supplementary Services Table Parameter Description
Parameter Description
General
Index
[ISDNSuppServ_Index]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
Global Phone Number
phone-number
[ISDNSuppServ_PhoneNumber]
Defines a global telephone extension number for the
endpoint. The global number is used for the following
functionalities:
Endpoint registration
IP-to-Tel routing
Mapping between local and global (E.164) numbers
between Tel and IP sides respectively
Local Phone Number
local-phone-number
Defines a local telephone extension number for the
endpoint (e.g., the PBX extension number). The local
