User's Manual 736 Document #: LTRT-10632
Mediant 800B Gateway & E-SBC
Parameter Description
Group at Index 0, second call to IP Group at Index 2, third call to IP
Group at Index 3, and so on. If an IP Group is offline, the device
selects the next consecutive IP Group. Once the last IP Group in the
IP Group Set list is selected for a call, the device goes to the
beginning of the list and sends the next call to the first IP Group, and
so on.
 [1] Random Weight = The device selects IP Groups at random and
their weights determine their probability of getting chosen over others.
The higher the weight, the more chance of the IP Group being
chosen.
 [2] Homing = The device always attempts to send all calls to the first
IP Group in the table (i.e., lowest index). If unavailable, it sends the
calls to the next consecutive, available IP Group. However, if the first
IP Group comes online again, the device selects it.
Note: For the Random Weight optional value, use the 'Weight'
parameter in the IP Group Set Member table (below) to configure weight
value per IP Group.
Tags
tags
[IPGroupSet_Tags]
Assigns a Dial Plan tag that is used to determine whether the incoming
SIP dialog is sent to IP Groups belonging to this IP Group Set. The
parameter is used when IP-to-IP Routing rules are configured for
destination based on tags (i.e., 'Destination Type' parameter configured
to Destination Tag). For more information on routing based on
destination tags, see Using Dial Plan Tags for Routing Destinations on
page 761.
Note: If the IP Groups belonging to the IP Group Set are also configured
with Dial Plan tags, the Dial Plan tag configured for the parameter takes
precedence. If the same Dial Plan tag is also configured for other IP
Groups in the IP Groups table, the IP Group Set takes precedence and
the device sends the SIP dialog to the IP Group(s) belonging to the IP
Group Set.
5. Select the IP Group Set row for which you want to assign IP Groups, and then click
the IP Group Set Member link located below the table; the IP Group Set Member
table appears.
6. Click New; the following dialog box appears:
Figure 34-8: IP Group Set Member Table - Dialog Box
7. Configure IP Group Set members according to the parameters described in the table
below.
8. Click Apply, and then save your settings to flash memory.
