Version 7.2 77 Mediant 800B Gateway & E-SBC
User's Manual 6. Web-Based Management
Web interface and CLI) remotely through different IP addresses. Each additional
management interface can be configured to use a specific network interface (Control
and/or Media type) and TLS Context, and can be configured to restrict access through
HTTPS only.
Note:
• To allow access to the device's management interfaces through all network
interfaces in the IP Interfaces table, see the EnableWebAccessFromAllInterfaces
parameter. This parameter does not specify a TLS Context nor a connectivity
protocol (HTTP or HTTPS).
• Currently, additional management interfaces are not supported for REST API
(ARM).
The following procedure describes how to configure additional management interfaces
through the Web interface. You can also configure it through ini file
(AdditionalManagementInterfaces) or CLI (configure system > additional-mgmt-if).
 To configure additional management interfaces:
1. Open the Additional Management Interfaces table (Setup menu > Administration tab
> Web & CLI folder > Additional Management Interfaces).
2. Click New; the following dialog box is displayed:
Figure 6-29: Additional Management Interfaces Table - Add Dialog Box
3. Configure an additional management interface according to the parameters described
in the table below.
4. Click Apply, and then save your settings to flash memory.
Additional Management Interfaces Table Parameter Descriptions
Parameter Description
General
Index
[AdditionalManagementInt
erfaces_Index]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
Interface Name
interface-name
Assigns an IP network interface (from the IP Interfaces table) to the
management interface.
For more information on IP network interfaces, see Configuring IP
