2. Configurations, requirements and restrictions
When downloading the complete Projector Toolset, this software contains already the latest device plug-ins. When you already have
the latest core version of Projector Toolset, it is possible to download only device plug-in updates from the same web site location.
As Projector Toolset is a stand alone application, it is not necessary to install any other software. A Java virtual machine is included
with this download.
Installation
Download first the reference manual (Part number: R59770052) and follow the installation instructions as written in this manual.
2.7 Installation process overview
Quick setup
The following steps describe briefly how to setup your HDF W series projector in a table mount front projection. Note that each step
refers to a corresponding procedure, which is more detailed and illustrated.
1. Install the batteries of the remote control. See "RCU battery installation", page 19
2. Place the projector on a solid table in front of the screen at the expected throw distance. Ensure that t
he projector is installed at
right angles (horizontally and vertically) with the screen. See "Projector configurations", page 14.
3. Select and install an appropriate lens, which covers the throw ratio ( = screen size / projector screen distance). See "Lenses",
page 23.
4. Connect the projector with the local power net. See "Power connection", page 33.
5. Connect your source to the appropriate input module. See "Input source connections", page 40.
6. Switch ON the projector. See "Power on projector", page 47.
7. Select the input slot to which the source is connected. Do this by pressing the numeric key on the remote control unit or on the
local keypad, See "Source selection", page 53.
8. Zoom and shift the lens until the image is properly projected on the screen, Do this by using the “ZOOM” and “FOCUS” key on
the remote control unit or on the local keypad. If necessary, level the projector from side to side by turning the adjustable feet in
or out.
Check cooling liquid level at least every 6 months.
Every 6 months at device power up a message will be displayed on the local LCD to check the cooling liquid
level
18 R5905158 HDF W SERIES 10/07/2012
