17. Servicing
17. SERVICING
About this chapter
This chapter contains general servicing procedures like lamp house replacement, input unit replacement etc. These procedures
may only be performed by qualified technical service personnel.
Overview
• Inserting an input module
• Replacement of the dust filter on the front side
• Replacement of the dust filter on the bottom side
• Replacement of the dust filter on the top side
• Pressure verification of the liquid cooling circuit
• Removal of the lamp house
• Installation of the lamp house
• Realignment of the lamp in its reflector
Extra service information
Extra service information for qualified service technicians can be found on Barco’s Partnerzone (URL:http:\\my.barco.com). Regis-
tration is necessary.
If you are not yet registered, click on Partnerzone registration and follow the instructions. With the created login and password, it is
possible to enter the partnerzone where you can find extra service information about the projector.
WARNING: Switch off the projector and unplug the power cord before starting the procedure.
WARNING: Maximum service time is limited to 2 hours due to possible UV radiation.
17.1 Inserting an input module
WARNING: Switch off the projector and unplug the power cord before starting the procedure.
How to insert
1. Loosen both screws of the dummy cover plate (1). (image 17-1)
2. Take off the dummy cover plate.
3. Insert the new input module in its compartment.
Make sure the module seats in its sliders (2).
Pull in the module until the contacts (3) are fully inserted into the connectors.
4. Fixate both fixation screws. (image 17-2)
R5905158 HDF W SERIES 10/07/2012
231
