3. Physical installation
3.2 Lenses
Overview
• Available lenses
• Lens selection
• Lens installation
• Lens removal
• Lens safety cable (optional)
• Lens shift, zoom & focus
• Scheimpflug adjustment
3.2.1 Available lenses
Available lenses for the HDF W series projector
Image 3-9
R9840775: TLD+ (1.16 : 1) fixed lens
Image 3-10
R9862000: TLD+ lens (0.67 : 1)
Image 3-11
R9862005: TLD+ zoom lens (1.16 - 1.49 : 1)
Image 3-12
R9862010: TLD+ zoom lens (1.39 - 1.87 : 1)
Image 3-13
R9862020: TLD+ zoom lens (1.87 - 2.56 : 1)
Image 3-14
R9862030: TLD+ zoom lens (2.56 - 4.16 : 1)
Image 3-15
R9862040: TLD+ zoom lens (4.16 - 9.6 : 1)
Image 3-16
R9829997: TLD+ zoom lens (9.6 - 10.39 : 1)
R5905158 HDF W SERIES 10/07/2012 23
