A. Specifications
A. SPECIFICATIONS
A.1 Specifications of the HDF W22
Overview
Projector type WUXGA three-chip DLP digital projector
Technology 0.96’ DMD™ x3
Resolution 1920x1200
Brightness 22,000 center lumens
20,000 ANSI lumens
Contrast ratio 1,900:1 (standard)
2,400:1 (high contrast mode)
Brightness uniformity 90%
Aspect Ratio 16:10
ScenergiX
Horizontal and vertical edge blending
Lens type
TLD+
Lenses
TLD+ (fix)
0.73:1
1.2:1
1.25-1.6:1
1.5-2.0:1
2.0-2.8:1
2.8-4.5:1
4.5-7.5:1
7.5-11.5:1
Optical lens shift Vertical: -10% to +110%
Horizontal: +/-30% (on zoom lenses memorised)
Color correction P7
Lamps
3.8 kW xenon
Lamp lifetime 1,000 Hrs
Transport with lamp Yes
Lamp house, quick replace Yes
Customer bulb replace Yes
Lamp warranty (field replace/
factory replace)
90 days, 500 hours / pro rata 500 hours
Sealed DLP™ core Standard
Optical dowser Standard
Picture-in-picture Two sources simultaneously
Orientation table - ceiling - side (portrait) - vertical
Others
can be controlled by DMX 512 console, warping
DMX 512 standard
WARP Preset values + custom
integrated web server
yes
CLO (constant light output) Standard
3D
Active eyewear (optional), passive Infitec (optional), passive circular (optional)
R5905158 HDF W SERIES 10/07/2012 241
