7. Start up of the adjustment mode
When the bar scale is displayed, via direct input. Press ENTER to activate the input field.
Image 7-4
Direct contrast adjustment
Enter the desired value with the digit keys. Press ENTER to accept.
Press EXIT to finalize the adjustment.
7.5 Menu memory
Overview
Each menu with sub menus, remembers its last selected sub item even when leaving the menu structure and that as long as the
projector is running. When restarting the projector from stand-by, the menu memory is reset.
After re-opening the main menu and selecting an item, the previous selected sub item of that selected item is highlighted and can
be opened just by pressing ENTER.
7.6 Shortcut keys to the menus
About a shortcut key
The digit keys 5 to 9 can be customer programmed to directly open a pre-stored menu. That menu can be any independent menu
out of the list of menus. A menu which is built up by the content of a previous menu cannot be stored behind a shortcut.
How to use a shortcut key
While in the operational mode, no menu selected, just press on the d
esired digit key to open the menu behind that shortcut key.
How to create a shortcut key
Scroll to the desired menu. Press the digit key behind which the menu must be stored for 5 seconds. When the creation is success-
fully, a confirmation message appears on the screen. E.g. :
Image 7-5
Select Yes to confirm the creation.
To erase the shortcut, navigate to Projector Control → Buttons.
7.7 Test patterns in adjustment mode
Overview
When the adjustment mode is started, a test pattern can be called at any moment just by pressing the Pattern key on the RCU or the
local key path. Press as many times on the Pattern key as necessary to display the desired test pattern. The test pattern remains
on the screen as long as the adjustment mode is selected, even when selecting other menus. When leaving the adjustment mode,
the selected test pattern is cleared and the normal image is displayed again.
R5905158 HDF W SERIES 10/07/2012
65
