7. Start up of the adjustment mode
7. START UP OF THE ADJUSTMENT MODE
Overview
• About the adjustment mode
• About the use of the remote control and the local keypad
• Start up the adjustment mode
• Navigation and adjustments
• Menu memory
• Shortcut keys to the menus
• Test patterns in adjustment mode
• Help information in adjustment mode
7.1 About the adjustment mode
Overview
As the adjustment mode is the central place to control and align the projector, the following functions can be done:
• Input setup: different Input settings can be adjusted such as specific input slot settings, locking, native resolution and no signal
settings.
• Image adjustment: these adjustments are organized per image source and contain the aspect ratio, timings and image settings.
• Layout adjustment: set up of the main window and the picture in picture window.
• Lamp: manage the lamp mode, the lamp use, lamp type and history
• Alignment: groups all controls necessary during the setup of the projector onto a screen.
• Projector control: contains the accessibility settings of the projector, such as address and communication setup.
• Service: contains information about how the projector is performing. This information will be useful when calling for a service
intervention.
7.2 About the use of the remote control and the local keypad
Overview
All navigations and adjustments can be done either with the remote control or with the local keypad.
Almost all the keys on the remote control have an equivalent on the local keypad.
Exceptions:
• Direct adjustment keys such as Contrast, Brightness, Saturation, Phase, etc.
7.3 Start up the adjustment mode
Start up tools
To start up the adjustment mode, use the remote control or the local keypad.
How to start up?
1. Press Menu on the remote control (RCU) or on the local keypad to start up the Adjustm ent mode.
The main menu of the adjustment mode opens. (image 7-1)
R5905158 HDF W SERIES 10/07/2012
63
