Barco HDF W series Installation Manual

A. Specifications
Lenses
TLD+ (fix)
0.73:1
1.2:1
1.25-1.6:1
1.5-2.0:1
2.0-2.8:1
2.8-4.5:1
4.5-7.5:1
7.5-11.5:1
Optical lens shift Vertical: -10% to +110%
Horizontal: +/-30% (on zoom lenses memorised)
Color correction
P7
Lamps
3.8 kW xenon
Lamp lifetime
750 Hrs
Transport with lamp Yes
Lamp house, quick replace Yes
Customer bulb replace
Yes
Lamp warranty (field replace/
factory replace)
90 days, 500 hours / pro rata 500 hours
Sealed DLP™ core Standard
Optical dowser Standard
Picture-in-picture Two sources simultaneously
Orientation table - ceiling - side (portrait) - vertical
Others can be controlled by DMX 512 console, warping
DMX 512 standard
WARP Preset values + custom
integrated web server
yes
CLO (constant light output) Standard
3D Active eyewear (optional), passive Infitec (optional), passive circular (optional)
Inputs DVI-I (HDCP including analog RGB YUV), SDI/HDSDI/Dual HDSDI/3G/BarcoLink
Optional Inputs 5-BNC RGBHV (RGBS/RGsB, YUV CS/SOY, Composite video, S-Video); DVI-I (HDCP
including analog RGB YUV) + SDI/HDSDI/Dual HDSDI/3G; 3D (HDMI/DisplayPort)
Input Resolutions
From NTSC up to QXGA (2048x1536)
max. pixel clock 200 MHz
Software tools
Projector Toolset
Control XLR wired + IR, RS232, Wifi, GSM (opt)
Network connection
10/100 base-T, RJ-45 connection, Wifi (optional)
Power Requirements
200-240V / 50-60Hz
Max. power consumption 4,550W
STBY < 10W
Noise level (typical at 25°C/77°F)" 60dB(A)
Operational ambient temperature 0-40°C / 32°-104°F
Operational humidity 0-80% (non condens)
Dissipation BTU Max. 15593 BTU/h
Dimensions (WxLxH) 707 x 1025 x 548mm
27.83 x 40.35 x 21.57 inches
Weight
99kg (218.25lbs)
R5905158 HDF W SERIES 10/07/2012 243

Barco HDF W series Specifications

General

Brand	Barco
Model	HDF W series
Category	Projector
Language	English
