E. Stacking HDF W series projectors

Zoom

Image E-10

Zoom adjustment

In case of a triple stacked table mount projector conﬁguration adjust and align ﬁrst the bottommost projector

(reference), than the projector in the middle and ﬁnally the uppermost projector.

R5905158 HDF W SERIES 10/07/2012 259
