4. Input & Communication
10 Power indication
11 IR indication
12 Lamp indication
13
ACT (activity) indication
14
Wifi select indication
15 IR receiver
12V output
12 V output, maximum 1A, available when projector is not in stand by.
DMX interface
DMX is used as communication bus between different devices in the light technic. Each device has an input and an output, so that
the bus can be looped between the different devices. According the standard a five wire cable with XLR connector is used.
You can use the DMX input port to connect a DMX device (DMX console) to the projector. This way you c
an control the projector
from that DMX device (console). The DMX output port can be connected with the next device in the loop.
Pin Description
1Earth
2
Cold
3Hot
4
Return - (or not used)
5
Return + (or not used)
DMX
DMX-512 Lighting protocol over RS-485 interface. Carries information of 512 channels from a lighting controller to
lighting devices. Standardized by USITT.
Wired remote control (XLR)
If desired the remote control unit can be wired and plugged in into the male XLR port on the communication interface.
XLR – Remote CTRL in
Pin Description
1
GND
2
RC5 in
3 XLR present sense
RS232/RS422 input
The communication interface of the HDF W series projector supports RS232 and RS422 serial communication on two different types
of input connectors. The left one a Sub-D conne
ctor, the right one an USBB connector acting as RS input when connected to an
USB input of a PC.
You can use the RS232/RS422 input to connect a local PC to your HDF W series projector. By this way you can configure and
control your HDF W series projector from your local PC.
Do not forget to set the projector’s baud rate to match that of the computer.
Advantages of using RS232/RS422 serial communication:
• easy adjustment of the projector via PC (or MAC).
• allow storage of multiple projector configurations and set ups.
• wide range of control possibilities.
• address range from 0 to 255.
• sending data to the projector (update).
• copying data from the projector (backup).
42
R5905158 HDF W SERIES 10/07/2012
