Canon LBP6780x - Page 115

To Next Page

To Previous Page

Push the ROM module into the printer firmly while aligning the module with the two connectors.

Attach the slot cover.

(1) Attach the slot cover.

(2) Close the cover.

(3) Attach and fasten the two screws.

Attach the right cover.

(1) Attach the right cover.

(2) Close the cover.

㻝㻝㻡㻌㻛㻌㻥㻣㻜
