Canon LBP6780x - Page 434

To Next Page

To Previous Page

IMPORTANT

When the [Use ARP/PING] check box is cleared

You cannot set the IP address using the ARP/PING command.

Proceed to Step 6 if you do not specify the settings for the other options.

FTP Settings

(1) Click [Edit...] in [FTP Settings].

(2) Set FTP print.

㻠㻟㻠㻌㻛㻌㻥㻣㻜
