Cisco MDS 9000 Series Configuration Guide

The show rlir erl command shows the list of Nx ports that are registered to receive the RLIRs with
the switch. If the VSAN ID is not specified, the details are shown for all active VSANs (see Examples
Displays All ERLs, on page 276 and Displays ERLs for the Specified VSAN, on page 276).
Displays All ERLs
switch# show rlir erl
Established Registration List for VSAN: 2
----------------------------------------------
FC-ID LIRR FORMAT REGISTERED FOR
----------------------------------------------
0x0b0200 0x18 always receive
Total number of entries = 1
Established Registration List for VSAN: 100
----------------------------------------------
FC-ID LIRR FORMAT REGISTERED FOR
----------------------------------------------
0x0b0500 0x18 conditional receive
0x0b0600 0x18 conditional receive
Total number of entries = 2
In Displays All ERLs, on page 276, if the Registered For column states that an FC ID is conditional
receive, the source port is registered as a valid recipient of subsequent RLIRs. This source port is
selected as an RLIR recipient only if no other ERL recipient is selected.
In Displays All ERLs, on page 276, if the Registered For column states that an FC ID is always
receive, the source port is registered as a valid recipient of subsequent RLIRs. This source port is
always selected as an LIR recipient.
If an always receive RLIR is not registered for any N port or if the delivery of an RLIR fails for one
of those ports, then the RLIR is sent to a port registered to conditional receive RLIRs.
Note
Displays ERLs for the Specified VSAN
switch# show rlir erl vsan 100
Established Registration List for VSAN: 100
----------------------------------------------
FC-ID LIRR FORMAT REGISTERED FOR
----------------------------------------------
0x0b0500 0x18 conditional receive
0x0b0600 0x18 conditional receive
Total number of entries = 2
In Displays the LIR History, on page 277, through Displays Recent LIRs for a Specified Port Number,
on page 277, if the host time stamp (marked by the *) is available, it is printed along with the switch
time stamp. If the host time stamp is not available, only the switch time stamp is printed.
Note
Cisco MDS 9000 Series Fabric Configuration Guide, Release 8.x
276
Configuring FICON
Displaying RLIR Information
