A53 Z0 9 0020 L En Technical documentation
activates with [+]+[SHIFT] keys or “Manual +U request [E2235];
-f activates with [-]+[SHIFT] keys or “Manual –U request
[E2236]. In Auto mode, these functions will control a speed /
voltage regulator requiring +/- contacts. You can configure the
no action range for the speed [E1598] and for the voltage
[E1599], the impulsion delay for the speed [E1600] and for the
voltage [E1601].
Will activate in stop sequence to stop the engine when
damping flap is fitted. Will be activated when there is an engine
fault [2046].
This will activate the output whenever the light test key is
pressed on the front panel of GENSYS 2.0, or an input
programmed for light test is active
Output will be active when start sequence is completed and
voltage is present at the generator. In Auto mode, the output
will be activated when the engine state is “Gen ready”. In
Manual mode the output will be activated when the speed
[E0033] is positive.
Output will be active when genset is at rest. In Auto mode, the
output will be activated when the engine state is “Waiting”. In
Manual mode the output will be activated when there is no
speed [E0033].
These key are useful in Manu mode to control the speed and
the voltage.
Output will be active when GENSYS 2.0 is in manual mode.
Will be active when a second engine starting system is present
and programmed in Configuration -> Start sequence menu.
Will be active when a third engine starting system is present
and programmed in Configuration -> Start sequence menu.
Output will be active when the measurement of analogue input
1 [oil pressure] is under the set value; it will not de-activate
until measurement is over [set value + hysteresis value]. To be
programmed and used with the following parameters: “Oil
threshold” [E1175], “Oil hysteresis” [E1176].
Output will be active when the measurement of analogue input
2 [water temperature] is over the set value; it will not de-
activate until measurement is under [set value minus hysteresis
value]. To be programmed and used with the following
parameters, “Wat temp thresh” [E1426], “Wat temp hyst.”
[E1427]
Output will be active when the measurement of analogue input
3 [1st spare measure] is over or under the set value; it will not
de-activate until measurement is under or over [set value +/-
hysteresis value]. To choose the direction of the protection, see
Configuration -> engine/battery settings [SS measure 1 min or
max thresh.].
To be programmed and used with the following parameters:
“Meas 1 thresh.” [E1428], “Meas 1 hyst.” [E1429].
