CRE Technology GENSYS 2.0 User Manual

A53 Z0 9 0020 L En Technical documentation
Chapter : I/O lines
99
Value
Function
Description
2727
Trip out 4
Output activated by the protection in the "Non essential
consumer trip" sequence. See §13.15; This is the 4th trip
activated [E1894] sec. after the previous one. Non Essential
consumer trip
2728
Trip out 5
Output activated by the protection in the "Non essential
consumer trip" sequence. See §13.15; This is the 5th trip
activated [E1894] sec. after the previous one. Non Essential
consumer trip
2774
TripOut direct
Output activated by the protection in the "Non essential
consumer trip" sequence. See §13.15; This one is activated
directly. Non Essential consumer trip
2213
Smoke limiter
Output to be used if external speed controller has smoke limit
input. Will activate an output upon start. In Manual mode:
when GENSYS 2.0 start button is pressed or with a manual start
request. In Auto mode: when engine state is “Start”, “Warm
up” and “Nominal speed”.
2214
Warm up
This output will activate when engine is warming up. Will
activate an output at start. In Manu mode, when GENSYS 2.0
start button is pressed or with a manual start request and while
the warm up timer [E2061] is different from 0. In Auto mode,
when engine state is “Start” and “Warm up”.
2206
Horn
Can be used for external horn or flashing light relay; output will
activate whenever a protection triggers. The output will be
activated when a generator electrical fault [E2200], mains
electrical fault [E2201], alarm [E2202], fault [E2203] or security
[E2204] triggers, and will reset when the GENSYS 2.0 horn
button is pressed.
Parameter E1991 can be used to select the maximum duration
of horn activation (0 means the horn will buzz until being
manually stopped).
2215
Air fans
To be wired to fan relay.
2219
Generator breaker
Close
Can be used to close genset breaker
(1)
2221
Generator breaker
Open
Can be used to open genset breaker
(1)
2220
Mains breaker Close
Can be used to close mains breaker
(1)
.
2222
Mains breaker Open
Can be used to open mains breaker
(1)
.
2229
Fuel filling
Can be used for an external fuel pump in conjunction with
"Fuel low level" and "Fuel high level" or "Manu fuel fill"
functions attributed to spare digital inputs.
2242
Coolant filling
Can be used for a compressor in conjunction with "Coolant high
level" and "Coolant low level" or "Manual air fill" functions
attributed to spare digital inputs.
2245
Oil filling
Can be used for oil level filling in conjunction with "Oil high
level" and "Oil low level" or "Manu oil fill" functions attributed
to spare digital inputs.
2341
+f
The behaviour will change according to the mode. In Manual
mode, if you program the +f function, the output will be
activated when you press the GENSYS 2.0 [+] key or if there is a
“Manual +f request” [E2233]. Likewise for the other functions; -
f activates with [-] key or “Manual –f request [E2234]; -f
2342
-f
