CRE Technology GENSYS 2.0 User Manual

A53 Z0 9 0020 L En Technical documentation
Chapter : I/O lines
98
Value
Function
Description
2083
Water preheat
Can be used for coolant pre heat system.
2084
Pre-lubrication
Can be used for pre lubrication pump.
2085
Pre glow
Can be used for cylinder pre heating plugs
2018
Crank
Can be used for external crank relay
2019
Fuel
Can be used for external fuel relay
2211
Excitation
Can be used to activate an external AVR in a static
synchronizing configuration [see Configuration -> power plant
overview]
Will activate an external excitation relay when engine state is:
engine ready; generator ready; wait after stop request; cool
down. In the case of dynamic paralleling [E1177 = 0], the
output will also be activated in the start , warm up, and
nominal speed states.
2212
Fuel (energize to
stop)
Can be used for an external relay if fuel solenoid has to be
energized to stop the engine. Will activate an external fuel
relay [Energize to stop] when engine is running [E0033 > 0] and
if there is an engine fault [E2046] or a stop request. In Manual
mode the stop request will be the “Stop key” [E2047] or the
“Manual stop request” [E2228] or no fuel [E2019 off].
2016
Generator breaker
order
Can be used to open or close genset breaker.
The outputs configured with this function will have exactly the
same behaviour as the outputs for the Generator breaker [E4
to E6].
2017
Mains breaker order
Can be used to open or close genset breaker.
The outputs configured with this function will have exactly the
same behaviour as the outputs for the Mains breaker [E1 to
E3].
2316
Faults summary
Will activate an output when there is at least one “fault”
triggered by GENSYS 2.0.
2202
Alarms summary
Will activate an output when there is at least one “alarm”
triggered by GENSYS 2.0.
2204
Hard shut down
summary
Will activate an output when there is at least one “serious
fault” (securities) triggered by GENSYS 2.0.
2203
Soft shut down
summary
Will activate an output when there is at least one “minor fault”
triggered by GENSYS 2.0.
2200
GE elec faults
summary
Will activate an output when there is at least one “generator
electrical fault” triggered by GENSYS 2.0.
2201
Mains elec. faults
summary
Will activate an output when there is at least one “mains
electrical fault” triggered by GENSYS 2.0.
2724
Trip out 1
Output activated by the protection in the "Non essential
consumer trip" sequence. See §13.15; This is the first trip; Non
Essential consumer trip
2725
Trip out 2
Output activated by the protection in the "Non essential
consumer trip" sequence. See §13.15; This is the 2nd trip
activated [E1894] seconds after the previous one. Non Essential
consumer trip
2726
Trip out 3
Output activated by the protection in the "Non essential
consumer trip" sequence. See §13.15; This is the 3rd trip
activated [E1894] sec. after the previous one. Non Essential
consumer trip
