A53 Z0 9 0020 L En Technical documentation
A fault « sensor lost » is enable if the speed is
null and the engine started.
A fault is enable if the breaker controls (Mains
or generator) don’t work correctly.
An alarm is enable if the breaker controls
(Mains or generator) don’t work correctly.
A fault is enable when the engine doesn’t stop
correctly.
A fault is enable if the requirements to start
the engine are not observed. (Water
temperature and oil prelubrification)
(1)
A fault is enable if the motor didn’t succeed to
start.
The unit could not synchronize to Mains/Bus.
Phase fault between the generator voltages.
Threshold protection (minimum or maximum)
of the analog input 1 (F1-F2)
Threshold protection (minimum or maximum)
of the analog input 2 (F3-F4)
Alarm when a maintenance must be done (See
§13.18)
A fault is enable if a CANopen bus error is
detected.
A J1939 CAN bus error is detected.
Overspeed detected by J1939-MTU.
Low oil pressure detected by J1939-MTU.
