CRE Technology GENSYS 2.0 User Manual

A53 Z0 9 0020 L En Technical documentation
Chapter : Additional functions
123
3/ Add message
Each message sends a maximum of 4 Analogue values to BSM II.
By using the CRE Config software :
 Set “Output address " to the correct Node ID of the BSM II.
 Set “Output Data Type” to Analog
 Set “Number of Outputs” (Max 4)
 Add equation described below
4/ Customize the variables sent to BSM II
All variables are transferred as analogue outputs from GENSYS 2.0 to BSM II.
Analogue output
GENSYS 2.0 Variable
AO1  AO8
E2432  E2439
AO9  AO16
E2682  E2689
AO17  AO32
E2708  E2723
All variables are transferred as analogue inputs from BSM II to GENSYS 2.0.
Analogue input
GENSYS 2.0 Variable
AI1  AI44
E0285  E0328
Transfer a variable from GENSYS 2.0 to BSM II
To do this, write the equation below in level 1.
Example:
This example copies the KW measurement (E0018) to Analog Output 1 (E2432).
@ Allocate AO1 (E2432) to the measure of kW (E0018)
E2432:=E0018;
Transfer several digital variables (max 15) via one analogue output.
Each bit of the AO is equal to a digital variable.
Example:
@ allocate AO8 to digital outputs
@Breaker mains(b6) + 6 Digital Outputs(DO6=b5 -> DO1=b0);
E2439:= 0;
E2439:= X2439 + (64*E2000) + (32*E2445) + (16*E2444) + (8*E2443) + (4*E2442) + (2*E2441) + E2440;
Note: In the PLC equation, variables are considered as signed integers. This means that bit 31 is the sign
and cannot be used.
