A53 Z0 9 0020 L En Technical documentation
Parameter [E1929] (Phase Offset – Option 8) will be reset (as all other parameters) during upgrade process.
Set it back to the desired value if needed (use of Dyn11 transformer for example).
ATTENTION: Boot firmware v2.xx and v3.xx do not support high capacity SDHC cards
(cards above 2 GB) or cards formatted using FAT32. Only use FAT16 SD cards up to 2 GB
on boot firmware v2.xx and v3.xx. Boot firmware v4.00 and above accept FAT32 SDHC
cards. To check your boot version, go into menu “System/About”.
To upgrade your module firmware, please follow those steps:
Connect your PC to the module internal Web site using password level 2.
Backup parameters and equations if necessary.
Copy the new firmware on an SD card and insert it into the module. Filename must respect format
XXXXXXXX.H86 and the file should be provided exclusively by CRE Technology or its distributor
network.
Go into menu « System/Firmware upgrade ».
Click on « List files ».
Select the file you want to program into the module.
Click on « Upgrade firmware ».
A bar graph indicates the progress of the process.
WARNING :
Always disconnect your module from other CRE Technology products when upgrading
firmware (disconnect it from the inter-GENSYS CAN bus). It is advised to disconnect all
connectors from your module (except power and Ethernet) during upgrade process.
After upgrading, enter the proper module number in your product before connecting it to
the inter-GENSYS CAN bus. Otherwise, other modules may behave abnormally.
Do not upgrade firmware on a running product.
