A53 Z0 9 0020 L En Technical documentation
17.2.1
Power plant overview
This menu displays the power plant parameters (parameters shared by different GENSYS 2.0 and/or
MASTER 2.0 units until 32 units):
1/ Power plant status
This screen displays the machine status [E2071] of each genset
2/ GE 01 to 16 - kW
This screen displays the percentage of nominal active power supplied by each genset (from 1 to 16) in real
time the [E0042 à E0057]
3/ GE 17 to 32 - kW
This screen displays the percentage of nominal active power supplied by each genset (from 17 to 32) in real
time the [E6000-E6030-E6060 … E6450]
4/ GE 01 to 16 – kVAR
This screen displays the percentage of nominal reactive power supplied by each genset (from 1 to 16) in
real time [E0132 to E0147]
5/ GE 17 to 32 – kVAR
This screen displays the percentage of nominal reactive power supplied by each genset (from 17 to 32) in
real time [E6001-E6031-E6061 … E6451]
6/ GE 01 to 16- nominal kW
This screen displays the nominal active power of each genset from 1 to 16 [E0073 to E0088]
7/ GE 17 to 32- nominal kWl
This screen displays the nominal active power of each genset from 17 to 32. [E6003-E6033-E6063… E6453]
8/ GE 01 to 16- nominal kVAR
This screen displays the nominal reactive power of each genset from 1 to 16 [E0089 à E0104]
9/ GE 17 to 32- nominal kVAR
This screen displays the nominal reactive power of each genset from 17 to 32 [E6004-E6034-E6064 …
E6454]
Note: These display pages fit according to the number of unit selected
