CRE Technology GENSYS 2.0 User Manual

A53 Z0 9 0020 L En Technical documentation
Chapter : Menu overview
200
17.2.2Generator electrical meter
1/ Global view generator
This screen displays all generator electrical meter in real time :
 Phase to phase voltage for each phase [E0003, E0004, E0005]
 Phase to neutral voltage for each phase [E0000, E0001, E0002]
 Current for each phase [E0006, E0007, E0008]
 Active power for each phase [E0009, E0010, E0011]
 Reactive power for each phase [E0012, E0013, E0014]
 Power factor for each phase [E0015, E0016, E0017]
 Average active and reactive power, frequency and power factor [E0018, E0019, E0020, E0021]
2/ Generator phase -phase volt
This screen displays the three phase to phase voltage measurements.
3/ Generator phase-neutral volt
This screen displays the three phase to neutral voltage measurements.
4/ Generator currents
This screen displays the three current measurements.
5/ Generator kW
This screen displays the three kW measurements.
6/ Generator kVAR
This screen displays the three kVAR measurements.
7/ Generator PF
This screen displays the three power factor measurements.
8/ Generator parameters
This screen displays generator average active and reactive power, frequency and power factor
measurements.
9/ Generator energy meters
This screen displays KWh and kVARh calculation.
Note: These display pages fit according to the voltage system selected (see §13.17)
