CRE Technology GENSYS 2.0 User Manual

A53 Z0 9 0020 L En Technical documentation
Chapter : Menu overview
201
17.2.3 Mains / Bus bars electrical meters
1/ Global view Mains/Bus
This screen displays all Mains/Bus electrical meter in real time :
 Phase to phase voltage for each phase [E0796, E0797, E0798]
 Phase to neutral voltage for each phase [E0793, E0794, E0795]
 Current for each phase [E0799, E0800, E0801]
 Active power for each phase [E0802, E0803, E0804]
 Reactive power for each phase [E0805, E0806, E0807]
 Power factor for each phase [E0808, E0809, E0810]
 Average active and reactive power, frequency and power factor [E0060, E0059, E0023, E0058]
2/ Mains/Bus phase-phase volt
This screen displays the three phase to phase voltage measurements.
3/ Mains/Bus phase neutral volt
This screen displays the three phase to neutral voltage measurements.
4/ Mains/Bus currents
This screen displays the three current measurements.
5/ Mains/Bus kW
This screen displays the three kW measurements.
6/ Mains/Bus kVAR
This screen displays the three kVAR measurements.
7/ Mains/Bus PF
This screen displays the three power factor measurements.
8/ Mains/Bus parameters
This screen displays Mains/Bus average active and reactive power, frequency and power factor
measurements.
9/ Mains/Bus parameters
This screen displays kWh and kVARh measurements.
10/ Mains/Bus energy meters
This screen displays kWh and kVARh measurements.
Note: These display pages fit according to the voltage system selected (see §13.17)
