CRE Technology GENSYS 2.0 User Manual

A53 Z0 9 0020 L En Technical documentation
Chapter : Description
27
Terminal
Description
Terminal
capacity
(mm² / AWG)
Comment
H3
Shield
2.5 / 12
Compatible with most regulators. Details in §10.3
H4
AVR out -
2.5 / 12
J1
Mains breaker in
2.5 / 12
Digital input with 10kΩ pull-up dedicated to
Mains breaker feedback.
Accepts NO or NC contact to 0V.
Not isolated.
J2
Gen breaker in
2.5 / 12
Digital input with 10kΩ pull-up dedicated to
generator breaker feedback. Accepts NO or NC
contact to 0V.
Not isolated.
J3
Remote start/stop
2.5 / 12
Digital input with 10kΩ pull-up dedicated to
remote start/stop request in Auto mode. Accepts
NO or NC contact to 0V.
Not isolated.
J4
Oil pressure
Spare input
2.5 / 12
Digital input with 10kΩ pull-up.
Default factory set as input for oil pressure fault.
Accepts NO or NC contact to 0V.
Not isolated. Can be programmed as a spare
input. Details in §11.1
J5
Water temp
Spare input
2.5 / 12
Digital input with 10kΩ pull-up.
Default factory set as input for water
temperature fault.
Accepts NO or NC contact to 0V.
Not isolated. Can be programmed as a spare
input. Details in §11.1
J6 to J15
Spare input
1 to 10
2.5 / 12
Digital input with 10kΩ pull-up.
10 inputs can be configured with a specific
function or programmed with PLC equations.
Accepts NO or NC contact to 0V.
Not isolated. See details in §11.1.
K1
Power Tank
2.5 / 12
Only used for 12V power supply backup during
crank time. An externally supplied capacitor can
be connected between terminal K1 (+) and K3 (-)
for better tolerance to power drops. A 47.000µF
capacitor can help accept a 200ms power drop.
K2
Power supply +
2.5 / 12
9 to 40V, 10W consumption. Protected against
