CRE Technology GENSYS 2.0 User Manual

A53 Z0 9 0020 L En Technical documentation
Chapter : Dedicated I/O lines
73
The ESG offset adjustment [E1077] can be set between -100 and +100 (-10VDC to + 10VDC), and is added to
the external speed reference (G11).
Notes :
The Speed ref (G11) doesn't need to be connected if there is no voltage reference available.
0V must be wired with 4 mm² cable as follows: battery  speed governor  GENSYS 2.0.
See table below for presets. For specific settings contact your dealer.
Manufacturer
Model
ESG
Amplitude
(1076)
ESG
offset
(1077)
Terminal
G9 (out)
Terminal
G11 (ref)
Remark
HEINZMANN
E6
10%
0%
B3
KG6 /
System E6
-25.00%
46.50%
E3
NC
PANDAROS
DC6
24%
26%
B3
A3
Voltage
converter to
isolate the
signal on the
line. (DC/DC)
(advise)
CUMMINS
ECM pour
QSK23 /
QSK40 /
QSK45 /
QSX15 /
QSK 60
1.00%
00.00%
10 (Barber
Colman
Frequency
bias input)
06 (5Volts)
EFC
2%
0%
8
9
See Figure 41 –
Connection
with EFC
Cummins
ECM
(QST30)
1.00%
-3.00%
18
15(7,75v)
BARBER
COLMAN
All models
with analog
input
5%
-1.65%
ILS input
4v
DPG 2201
10%
-1.05%
ILS signal
2,5V
1.6%
-27%
ILS signal
Digital
supply
(+5V)
1.6%
25%
ILS signal
BAT-
