Chapter : Dedicated I/O lines

Manufacturer

Model

ESG

Amplitude

(1076)

ESG

offset

(1077)

Terminal

G9 (out)

Terminal

G11 (ref)

Remark

WOODWARD

- 2301A/D

ILS+speed

- (Without

U&I)

25.00%

90.00%

25.00%

Shunt 14-16

Shunt 26 (com)

on 0V

2301D

25.00%

00.00%

G11 connected

to 0v

2301A

Speed only

99.00%

-1.00%

16 connected

to 0V

Pro-act /

Pro-act II

25.00%

00.00%

Aux +

Aux -

Aux- connected

to 0V

EPG System

( P/N :

8290-189 /

8290-184)

25.00%

30.00%

11-12 open

MTU

MDEC

25.00%

20.00%

31 (5v)

Programmable

VOLVO

EDC 4

15.00%

25.50%

24 / conn.

25 / conn.

EDC III

20.00%

25,00%

Pot signal

PERKINS

ECM

25.00%

3 (5v)

Deutz

EMR

8.00% to

13.50%

26.20%

+/- 1.5 Hz not

to reach EMR

over-speed

TEM

compact

See §13.9

GAC

All ESD

-20%

-63.8%

Ghana Control

PWC 2000

75.5%

-25%

SCANIA

16 ltr full

electronic

engine

20%

-36%
