CRE Technology GENSYS 2.0 User Manual

A53 Z0 9 0020 L En Technical documentation
Chapter : I/O lines
95
Value
Function
Description
2205
Fault reset request
If an external reset is wired to the input, choose fault
reset request. This will have the same effect as pressing
the reset key on the GENSYS 2.0 front panel on Fault and
Alarm displays.
2227
Manual start request
To be selected if a remote start command is to be
installed.
2228
Manual stop request
To be selected if a remote stop command is to be
installed - different from emergency stop.
2233
Manual +f request
To be selected if a remote frequency increasing
command is to be installed.
2234
Manual -f request
To be selected if a remote frequency decreasing
command is to be installed.
2235
Manual +U request
To be selected if a remote voltage increasing command
is to be installed.
2236
Manual -U request
To be selected if a remote voltage decreasing command
is to be installed.
2231
Fuel high level
To be selected for a max level sensor or a calculation;
can be used in conjunction with digital transistor output.
2230
Fuel low level
To be selected for a min level sensor or a calculation;
can be used in conjunction with digital transistor output.
2244
Coolant high level
To be selected for a max level sensor or a calculation;
can be used in conjunction with digital transistor output.
2243
Coolant low level
To be selected for a min level sensor or a calculation;
can be used in conjunction with digital transistor output.
2247
Oil high level
To be selected for a max level sensor or a calculation;
can be used in conjunction with digital transistor output.
2246
Oil low level
To be selected for a min level sensor or a calculation;
can be used in conjunction with digital transistor output.
2197
Securities inhibition
Will inhibit all protections. These alarms and faults
remain listed in the faults and alarm logging.
2198
No cranking
To be selected to prevent engine from starting.
2210
Ext. secu.(Hard shut
down)
If external protections are installed, for immediate stop
of the engine. See recommendations in "Directions"
paragraph.
2209
Ext. fault(Soft shut down)
If external protections are installed, for immediate
opening of genset breaker and stopping of the engine
after cooling down timer has expired. See
recommendations in "Directions" paragraph.
2208
External alarm
If external protections are installed, to report an alarm.
See recommendations in "Directions" paragraph.
2217
Generator electrical fault
If external protections are installed, protection will open
genset breaker and try to synchronize again. See
recommendations in "Directions" paragraph.
2218
Mains electrical fault
If external protections are installed, protection will open
mains breaker and try to synchronize again. See
recommendations in "Directions" paragraph.
2681
Non essential trip alarm
Remote non essential load.
2736
Help + Fault ( Soft shut
down)
To be selected to stop the engine after cool down. The
GENSYS 2.0 will ask another engine to start before
stopping itself.
