348 | Data Center Bridging (DCB)
www.dell.com | support.dell.com
Table 13-6. Example: dot1p-Queue Assignment
Lossless SAN traffic with dot1p priority 3 is assigned to queue 1. Other traffic types are assigned the
802.1p priorities shown in Table 13-7 and the bandwidth allocations shown in Table 13-8.
Table 13-7. Example: dot1p-priority class group Assignment
Table 13-8. Example: priority group-bandwidth Assignment
dot1p Value in Incoming Frame Queue Assignment
00
10
20
31
42
53
63
73
dot1p Value in Incoming Frame Priority Group Assignment
0 LAN
1 LAN
2 LAN
3 SAN
4 IPC
5 LAN
6 LAN
7 LAN
Priority Group Bandwidth Assignment
IPC 5%
SAN 50%
LAN 45%
