Dell Force10 S4810P

Force10 Resilient Ring Protocol (FRRP) | 427
Configure and add the Member VLANs
Control and Member VLANS are configured normally for Layer 2. Their status as Control or Member is
determined at the FRRP group commands. For complete information about configuring VLANS in Layer 2
mode, refer to Layer 2.
2 tagged interface slot/
port {range}
CONFIG-INT-VLAN Tag the specified interface or range of interfaces
to this VLAN.
Interface:
• For a 10/100/1000 Ethernet interface, enter
the keyword keyword GigabitEthernet
followed by the slot/port information.
• For a Gigabit Ethernet interface, enter the
keyword
GigabitEthernet followed by the
slot/port information
• For a 10 Gigabit Ethernet interface, enter the
keyword
TenGigabitEthernet followed by the
slot/port information.
•
For a 40-Gigabit Ethernet interface, enter the
keyword
fortyGigE followed by the slot/port
information.
Slot/Port, Range: Slot and Port ID for the
interface. Range is entered Slot/Port-Port.
3
interface primary int
slot/port secondary int
slot/port control-vlan
vlan id
CONFIG-FRRP Assign the Primary and Secondary ports, and the
Control VLAN for the ports on the ring.
Interface:
• For a 10/100/1000 Ethernet interface, enter
the keyword keyword GigabitEthernet
followed by the slot/port information.
• For a Gigabit Ethernet interface, enter the
keyword GigabitEthernet followed by the
slot/port information
• For a SONET interface, enter the keyword
sonet followed by slot/port information.
• For a 10 Gigabit Ethernet interface, enter the
keyword TenGigabitEthernet followed by the
slot/port information.
• For a 40-Gigabit Ethernet interface, enter the
keyword
fortyGigE followed by the slot/port
information.
Slot/Port: Slot and Port ID for the interface.
VLAN ID: The VLAN identification of the
Control VLAN.
4 mode master CONFIG-FRRP Configure the Master node
5 member-vlan vlan-id
{range}
CONFIG-FRRP Identify the Member VLANs for this FRRP
group
VLAN-ID, Range: VLAN IDs for the ring’s
Member VLANS.
6
no disable
CONFIG-FRRP Enable FRRP
Step Command Syntax Command Mode Purpose
