Be sure to follow these guidelines:
• All VLANS must be in Layer 2 mode.
• Control VLAN ports must be tagged. Member VLAN ports except the Primary/Secondary interface
can be tagged or untagged.
• The Control VLAN must be the same for all nodes on the ring.
Use the commands in the following sequence, on all of the Transit switches in the ring, to create the
Members VLANs for this FRRP group.
Step Command Syntax Command Mode Purpose
1
interface vlan vlan-id CONFIGURATION Create a VLAN with this ID number
VLAN ID: 1-4094
2
tagged interface slot/
port {range}
CONFIG-INT-VLAN Tag the specified interface or range of interfaces
to this VLAN.
Interface:
• For a 10/100/1000 Ethernet interface, enter
the keyword keyword
GigabitEthernet
followed by the slot/port information.
• For a Gigabit Ethernet interface, enter the
keyword GigabitEthernet followed by the
slot/port information
• For a SONET interface, enter the keyword
sonet followed by slot/port information.
• For a 10 Gigabit Ethernet interface, enter the
keyword TenGigabitEthernet followed by the
slot/port information.
• For a 40-Gigabit Ethernet interface, enter the
keyword
fortyGigE followed by the slot/port
information.
Slot/Port, Range: Slot and Port ID for the
interface. Range is entered Slot/Port-Port.
3 interface primary int
slot/port secondary int
slot/port control-vlan
vlan id
CONFIG-FRRP Assign the Primary and Secondary ports, and the
Control VLAN for the ports on the ring.
Interface:
• For a 10/100/1000 Ethernet interface, enter
the keyword keyword GigabitEthernet
followed by the slot/port information.
• For a Gigabit Ethernet interface, enter the
keyword GigabitEthernet followed by the
slot/port information
• For a SONET interface, enter the keyword
sonet followed by slot/port information.
• For a 10 Gigabit Ethernet interface, enter the
keyword TenGigabitEthernet followed by the
slot/port information.
• For a 40-Gigabit Ethernet interface, enter the
keyword
fortyGigE followed by the slot/port
information.
Slot/Port: Slot and Port ID for the interface.
VLAN ID: Identification number of the Control
VLAN
