OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
WIND COMPONENTS, NAVIGATION ANGLES AND AIR DATA
Display the PROGRESS 4/4 page by pressing [PROG] and [PREV].
PROGRESS 4/4 page includes the display of wind, aircraft heading, drift angle, true air speed, magnetic
variation, and altitude.
The HEADWIND (TAILWIND) field displays the present headwind or tailwind components in knots. The sense
of the CROSSWIND component is the side FROM which the wind is blowing.
OFFSET TRACK INITIATION
Display the ACT RTE x 1/X page by pressing [RTE].
1. Enter the desired track offset in nautical miles (e.g.: L10.0) and move the entry into the OFFSET field by
pressing LSK 6R.
1R
2R
3R
4R
5R
PROGRESS 4/4
HEADWIND CROSSWIND
027
KT R44KT
HDG/DA TAS
290
o
/ L11
o
240KT
MAGVAR
E019.9
o
ALT(CORR)
34245
FT
QNH SET
> 29.92
INHG
1L
2L
3L
4L
5L
6L
6R
ACT RTE 1 1/3
ORIGIN DEST
KSEA PANC
RUNWAY FLT NO
----- KL007
ROUTE
KSEAPANC1
CO RTES>
USER RTES>
OFFSET
<RTE 2 CYVR R0.0NM
1R
2R
3R
4R
5R
6R
1L
2L
3L
4L
5L
6L
