OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
WAYPOINT LATITUDE/LONGITUDE DISPLAY
Display the coordinates for each waypoint by pressing [LEGS], <LEGS ETA> (LSK 6R), <LEGS POS>
(LSK 6R).
Return to the LEGS page by pressing [LEGS] or the <LEGS> prompt (LSK 6R).
NOTES:
1. Flight plan waypoint modifications are not permitted on the RTE x LEGS POS Y/X page.
2. Required Navigational Performance (RNP) is also displayed if a value is defined for a leg in the
Navigational Database
PROGRESS ALONG THE ROUTE (DISTANCE-TO-GO, ETA)
Please refer to Appendix F, CMA-9000 FMS RRJ VNAV
REQUIRED TIME OF ARRIVAL COMPUTATION
Please refer to Appendix F, CMA-9000 FMS RRJ VNAV
1R
2R
3R
4R
5R
ACT RTE 1 LEGS POS 1/2
CAFTA RNP 1.00NM .
N51
o
17.72 W129
o
05.32
YZP RNP 1.00NM
N53
o
15.13 W131
o
48.42
MOCA1
N54
o
30.18 W133
o
01.90
BKA
N56
o
51.57 W135
o
33.08
KILLA
N58
o
44.98 W140
o
35.10
<LEGS WIND LEGS>
1L
2L
3L
4L
5L
6L
6R
Page 5-17
August 17, 2010
DRAFT
