OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
To initialize the position use the POS INIT/REF 1/3 page:
POS INIT/REF 1/3
FMS POS GPS
N47
o
26.28 W122
o
18.67
REF AIRPORT
KLAX N47
o
26.28 W122
o
18.67
GATE
UTC DATE
1757:04z OCT20/10
<SETUP ROUTE>
1L
2L
3L
4L
5L
1R
2R
3R
4R
5R
1. Enter the airport identifier into the scratchpad.
2. Move the airport identifier to the REF WAYPOINT field by pressing LSK 2L.
REF WAYPOINT and IRS mode fields blank on aircraft lift-off.
3. Line select airport or IRS position into the scratchpad (by pressing LSK 2R or LSK 4R, or enter any other
desired position into the scratchpad (e.g. N472628W1221867).
4. Move the new position to the POSITION field by pressing LSK 1R.
ANGULAR REFERENCES FOR NAVIGATION AND DISPLAY
Display the INIT/REF INDEX 1/2 page by pressing [INIT REF]. From the INIT/REF INDEX 1/2 page, display the
SETUP 1/1 page by pressing <SETUP> (LSK 5L).
The default angular reference of all NAVIGATION DISPLAYS (heading, course, actual track, and bearing) is
MAGNETIC NORTH (degree symbol), and that of WIND DIRECTION is TRUE NORTH (T symbol).
6R
6L
FMS1 SETUP 1/1
DISPLAY
>MAG
FMS OPERATION
>SYNCHRONIZED
<POS INIT ROUTE>
1R
2R
3
R
4R
5R
6R
1L
2L
3L
4L
5L
6L
