Esterline CMA-9000 - POS INIT;REF 3;3 (for LASEREF_V Interface Configuration

OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
Page A-52
August 17, 2010
BRG (2R): Displayed only if the LSK is toggled to display BRG. Bearing from the FMS present position (FMS
POS) to each navigation mode position is displayed relative to True (superscript T indicates true North) or
Magnetic North (based on the setting on the SETUP page).
SETUP [6L]: Access to the SETUP 1/1 page.
ROUTE [6R]: When on the ground, access to the active RTE 1/X page.
NAV STATUS [6R]: When airborne, access to the NAV STATUS INDEX 1/1 page.
POS INIT/REF 3/3 (for LASEREF_V interface configuration)
Display the POS INIT/REF 3/3 page by pressing [INIT REF], <POS INIT>, [NEXT] and [NEXT] or [INIT REF],
<IDENT>, <POS IINIT>, [NEXT] and [NEXT].
This page allows the crew to verify the individual IRS position and ground speed against the active navigation
solution (FMS POS + ground speed). It also allows verifying the individual IRS status, action code, and update
mode.
A. For LASEREF_V:
1R
2R
3R
4R
5R
6R
POS INIT/REF 3/3
FMS POS GPS GSKT
N47
o
32.4 E122
o
18.50 250
IRS1 (14 MIN)
N47
o
32.3 E122
o
18.66 249
IRS2 (ATT)
N47
o
32.4 E122
o
18.55 250
IRS3 REJ
N47
o
32.3 E122
o
18.77 251
<SETUP
1L
2L
3L
4L
5L
6L
